Raycus RFL-CE Fiber Laser Source
Models available: RFL-3000CE (3 kW), RFL-6000CE (6 kW)
Key Highlights
- Continuous-wave fiber laser for industrial cutting and welding
- Wavelength: 1080 ± 5 nm (typical)
- Stable output: power stability up to ±1.5% (typ.)
- Control: analog (0–10 V) and/or serial interface (RS-type; exact options per unit)
- Modulation: supports high-frequency gating (exact limit depends on model/config)
- Output connector: QBH (default; other connectors on request)
- Supply: 380 V AC, three-phase, 50/60 Hz
- Cooling: external industrial water chiller required
- Typical use: carbon steel, stainless steel, aluminum alloys cutting/welding
Model Comparison
| Parameter | RFL-3000CE | RFL-6000CE |
|---|---|---|
| Rated output power | 3 kW | 6 kW |
| Central wavelength | 1080 ± 5 nm (typical) | |
| Output fiber core (typ.) | 50–75 μm (configurable) | 50–75 μm (configurable) |
| Output connector | QBH by default; other types available on request | |
| Power stability (typ.) | ±1.5% | |
| Input supply | 380 V AC, three-phase, 50/60 Hz | |
| Cooling | Closed-loop water chiller (capacity determined by site requirements) | |
What We Need Before Shipping
- Model: RFL-3000CE or RFL-6000CE
- Output connector: QBH (default) or other type (please specify)
- Delivery fiber length: required length and routing constraints
- Cooling specs: available chiller capacity and interface
- Electrical environment: 380 V three-phase availability and grounding
- Head/gantry info (for compatibility): cutting/welding head brand & model, control card
In the Box
- Raycus RFL-CE fiber laser source (selected model)
- Fiber delivery cable (length/spec per order)
- Standard accessories and documentation
Applications
High-precision cutting and welding of carbon steel, stainless steel and aluminum alloys in sheet-metal fabrication, machinery, automotive parts, and general metalworking.
Ordering & Lead Time
- Lead time depends on configuration. Contact us for stock status and dispatch date.
- Freight: UPS/DHL or dedicated freight by region. We provide tracking and export paperwork.
- Warranty/after-sales: technical guidance available; formal warranty terms provided with the order.
Notes
Parameters above are typical and may vary with configuration. For the official datasheet and a compatibility check, please contact our team with your machine details.
Need help choosing between 3 kW and 6 kW? Tell us your material type/thickness, speed targets, and existing head/chiller specs—we’ll recommend a matched setup.
